- Supported Protocols: SIP 2.0 over UDP/TCP/TLS
- Access Methods: Password, IC Card, DTMF Code, Remote Door Opening, BLE
- Interface: Wiegand Input / Output, Short Circuit Input / Output
- Supported Wiegand: 26, 34 bit
- Supported ONVIF Types: Profile S
- Supported Standards: DTMF, IC Card, Indoor Switch, BLE, Cards 13.56 MHz
- Speaking Mode: Full Duplex (High Definition)
- Additional: Built-in Relay, Motion Detection, Tamper Alarm, TF Card, Open API
- Body Material: ABS & OC
- Colour: Black Panel, Gunmetal Housing
- Sensor: 1/2.9-inch, CMOS
- Camera: 2 Megapixel, Supports Infrared
- Viewing Angle: 140° (FOV), 100° (Horizontal), 57° (Vertical)
- Output Video: H.264 (Baseline, Main Profile)
- Light Sensitivity: 0.1Lux
- Card Storage: 1,0000
- Power Consumption: PoE: 1.63~6.93W, Adapter: 1.51~6.16W
- Power Supply: DC 12V / 1A, PoE 802.3af Class 3
- IP Level: IP65
- Panel Size: 70.7mm x 149.7mm x 30mm (L x W x D)
- Installation: Wall Mount, Rain Cover Included
- Keyboard: 1 Speed Dial Button and Numeric Keypad
