Want it by tomorrow? Order within for next business day delivery 20 hours 59 mins 30 secs

2 PORT DUAL HDMI 4K60 KVMP 3.6 kg

£308.10£369.72 (VAT Excl.)(VAT Incl.)

  • Dual Display Sharing: Shares two displays and USB devices between 2 computers.
  • Flexible Modes: Supports Single PC mode (dual-head output from one computer) and Dual PC mode (each display assigned to a different computer).
  • Efficient Switching: Ideal for managing multiple systems with seamless display control.
Vendor:Aten SKU: CS1842 Barcode: 4710469340031

Product Specification
  • Models: UEH4002AL (Local Unit), UEH4002AR (Remote Unit)
  • Connectors:

    USB Port: UEH4002AL – 1 x USB Type B Female; UEH4002AR – 4 x USB Type A Female
    Link: 1 x RJ-45 Female (both models)
    Power: UEH4002AL – N/A; UEH4002AR – 1 x DC Power Jack

  • USB Specification: USB 2.0 High / Full / Low Speed (both models)
  • USB Devices Supported: UEH4002AR supports up to 4 USB devices
  • Power Consumption:

    UEH4002AL: DC 5V, 2.5W (12 BTU/h)
    UEH4002AR: DC 5V, 15W (66 BTU/h)

  • Environmental:

    Storage Temperature: -20°C to 70°C
    Operating Temperature: 0°C to 50°C
    Humidity: 0–80% RH, Non-condensing

  • Physical Properties:

    Weight: UEH4002AL – 0.17 kg (0.39 lb); UEH4002AR – 0.19 kg (0.42 lb)
    Housing: Metal
    Dimensions (L x W x H): 10.00 x 7.60 x 2.60 cm (3.94 x 2.99 x 1.02 in.)

  • Notes:

    Watt values indicate typical power consumption without external load.
    BTU/h values indicate power consumption at full load.
    Rack mount product dimensions may be expressed in L x W x H format.

Box Content
  • 2 PORT DUAL HDMI 4K60 KVMP

Documents

Datasheet

Technical Features

  • AV Interface: HDMI®
  • Console Interfaces: USB
  • Interface Standard: HDMI® 2.0, USB 3.0
  • Maximum Resolution: 4096x2160 @60Hz (4:4:4, 8-bit)
  • HDCP Support: 2.3
  • Supported Audio: HDMI® Pass Through, Analogue Stereo
  • Audio Ports: 3.5mm (Female)
  • Serial Interface: 3-pin Terminal Block
  • Console Number: 1
  • Max PCs/Servers: 2
  • Cascadable: No
  • Switching Method: Push Button, Mouse & Keyboard Hotkeys, IR Remote, RS-232 Commands
  • Rack Mountable: No
  • Special Features: USB 3.0 ports, dual head support, LED indicators

  • Connectors:
    • Console: 2 x HDMI® Type A (Female), 4 x USB Type A (Female), 3.5mm (Female)
    • PC/Server: 4 x HDMI® Type A (Female), 2 x USB 3.0 Type B (Female)
    • Other: 3-pin Terminal Block, 3.5mm IR (Female)
    • Power: 5.5/2.1mm DC socket

  • Physical Properties:
    • Dimensions (W x D x H): 220 x 100 x 30 mm (8.66 x 3.94 x 1.18 in.)
    • Housing: Metal
    • Weight: 0.609 kg (1.34 lb)
    • Operating Temperature: 0°C to 40°C
    • Storage Temperature: -20°C to 60°C
    • Humidity: 20–90% RH (non-condensing)
    • Power Requirement: 12V, 1A
    • Colour: Black

Description

This KVM Switch can share 2 displays and USB devices between 2 computers in different modes: Single PC mode with both video showing the dual head input from one source; Dual PC mode with the first display fixed on the first PC1 input and the second display fixed on the first PC2 input.
