YEASTAR P560 CONTROLLER (100/200 USERS)
Enterprise Communication Made Easy
Product Specification
Box Content
Documents
Overview
The Yeastar P560 Controller is a powerful P-Series IP PBX appliance built to support growing organizations requiring reliable and scalable communication infrastructure. Designed for 100 users (expandable to 200 users via licensing), it integrates telephony, conferencing, messaging, and collaboration into a single unified platform. The system supports SIP trunks, analog lines, and mobile connectivity through modular expansion options, ensuring flexible deployment. Built-in Linkus Unified Communications applications allow seamless communication across desktop, web, and mobile devices, enabling hybrid and remote work environments. With enterprise-grade security, centralized management, and advanced call handling capabilities, the P560 enhances productivity while reducing communication costs.
Technical Features
- Brand: Yeastar
- Model: P560 (P-Series Appliance Edition)
- System Type: IP PBX / Unified Communications Controller
- Supported Users: 100 (Expandable up to 200)
- Concurrent Calls: Up to 60
- Ethernet Ports: 2 × Gigabit RJ45
- Telephony Interfaces: Modular (FXS, FXO, BRI, GSM/4G supported)
- VoIP Protocols: SIP, TCP, UDP, TLS, SRTP
- Voice Codecs: G.711, G.722, G.726, G.729A, GSM, iLBC
- Video Codecs: H.263, H.263P, H.264, MPEG4
- USB Port: 1 × USB (External storage supported)
- Storage Support: Up to 2TB external storage
- Management Interface: Web-based GUI
- Power Supply: AC 100–240V, 50/60Hz
- Mounting: 1U Rackmount
- Operating Temperature: 0°C to 40°C
