Overview
The ATEN PE6108G 8‑Port Metered & Switched eco PDU is a professional‑grade power distribution unit designed to efficiently manage and deliver power to multiple devices in data centers, server racks, and enterprise environments. This PDU features 8 IEC320 C13 outlets and supports remote on/off power control, power cycling, and real‑time power measurement through a browser‑based interface. With support for TCP/IP protocols and secure access via SSL/SNMP, it enables centralized and remote power management from anywhere on the network. The unit also includes proactive overload protection, customizable outlet naming, and event logging to ensure safety and control. Its 1U rack‑mount 19″ form factor and robust construction make it ideal for dense IT environments where reliability and power oversight are critical.
Technical Features
- Model: ATEN PE6108G
- Type: Metered & Switched eco PDU
- AC Outlets: 8 × IEC320 C13
- Nominal Input Voltage: 100‑240 VAC
- Maximum Input Current: 10 A Max
- Input Frequency: 50‑60 Hz
- Maximum Power: 2300 VA (Max)
- Network Interface: RJ‑45 Ethernet
- Protocols Supported: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, DHCP, NTP, DNS, SNMP v3
- Form Factor: 1U 19″ Rackmount
- Display: 3‑digit LED for current/IP display
- Weight: ≈2.8 kg
- Operating Temperature: 0 – 50 °C
- Storage Temperature: –20 – 60 °C
- Humidity: 0 – 80 % RH non‑condensing
- Color: Black
- Housing: Metal
